使用环境：周围环境空气温度随季节变化，但不超过40℃；周围环境空气相对温度大于90%
备注：样本所列规格（a型）为标准型，可根据用户的特殊要求制作如下型式：
1.改变l1、l2.l3等尺寸的结构；
2.制成立式、带防雨罩的结构（标准型为卧式）；
3.制成左出线（标准型为右出线），顶出线结构；
4.制成机壳可装制动器、编码器等结构；
5.风机电机可有异电压异频率的电制，防护等级提高，绝缘等级提高等特殊要求（标准型号电制380v50hz，防护等级ip55，绝缘等级f级）
this series ventilator has reliable performance, high efficiency, low noise, simple structure and easy installation.suitable for ventilation and heat dissipation of variable frequency speed regulating motors.
using the environment：
ambient air temperature varies with the seasons but does not exceed 40℃;the ambient air relative temperature is greater than 90% (when the temperature is 25℃).
note：
the specifications listed in the sample (type a) are standard types. the following types can be made according to the special requirements of customers：
1.change the l1, l2.l3 size structure;
2.it is made into a vertical structure with rainproof cover (the standard type is horizontal);
3.made left outgoing line (standard type is right outgoing line), top outgoing line structure;
4.the machine housing can be equipped with brakes, encoders and other structures;
5.fan motor can be different voltage and different frequency of the electrical system, improve the protection level, improve the insulation level and other special requirements (standard model of electrical system 380v50hz, protection level ip55, insulation level f).
outline and mounting dimensions drawing：
main technical parameters:
| model | d1 | d2 | l1 | l2 | l3 | l4 | β | η | r | n | x | d | note |
| g-71a | 132 | 136 | 12 | 42 | 136 | 1.5 | 4 | 3 | 3 | 8 | no lubrication | ||
| g-80a | 150 | 155 | 8 | 32 | 150 | 1.5 | 4 | 3 | 3 | 15 | no lubrication | ||
| g-90a | 169 | 172.5 | 14 | 39 | 155 | 1.5 | 4 | 3 | 3 | 12 | no lubrication | ||
| g-100a | 188 | 193 | 14 | 46 | 162 | 1.5 | 5 | 3.5 | 3 | 12 | no lubrication | ||
| g-112a | 210 | 217 | 14 | 51 | 166 | 1.5 | 5 | 3.5 | 3 | 12 | no lubrication | ||
| g-132a | 250 | 258 | 20 | 62 | 177 | 1.5 | 5 | 3.5 | 3 | 15 | no lubrication | ||
| g-160a | 300 | 308 | 20 | 86 | 201 | 33 | 2 | 5 | 3.5 | 4 | 15 | 20 | are there refueling holes as required by the order |
| g-180a | 340 | 352 | 25 | 96 | 248 | 34.5 | 2 | 5 | 3.5 | 4 | 12 | 20 | are there refueling holes as required by the order |
| g-200a | 380 | 394 | 30 | 110 | 262 | 45 | 2 | 6 | 4.5 | 4 | 12 | 20 | are there refueling holes as required by the order |
| g-225a | 430 | 443 | 31 | 106 | 268 | 36 | 2 | 6 | 4.5 | 4 | 12 | 20 | are there refueling holes as required by the order |
| g-250a | 470 | 482 | 29 | 150 | 312 | 40 | 2 | 8 | 5 | 4 | 12 | 20 | have gas hole |
| g-280a | 530 | 546 | 34 | 156 | 370 | 36.5 | 2 | 9 | 5.5 | 4 | 12 | 20 | have gas hole |
| g-315a | 600 | 616 | 82 | 222 | 436 | 38 | 2 | 13 | 6 | 4 | 12 | 20 | have gas hole |
| g-355a | 680 | 694 | 124 | 265 | 480 | 38 | 2 | 13 | 6 | 4 | 12 | 20 | have gas hole |
| g-400a | 700 | 787 | 82 | 280 | 500 | 38 | 3 | 13 | 6 | 4 | 12 | 20 | have gas hole |
| model | electric system | power(w) | current(a) | speed(r/min) | air volume(m³/h) | pressure(pa) | noise db(a) | wind vane diameter(mm) |
| g-71a | 380v 50hz | 35 | 0.09 | 2800 | 200 | 42 | 63 | 131 |
| g-80a | 380v 50hz | 60 | 0.24 | 2800 | 350 | 60 | 64 | 150 |
| g-90a | 380v 50hz | 60 | 0.24 | 2800 | 500 | 80 | 67 | 169 |
| g-100a | 380v 50hz | 60 | 0.24 | 2800 | 650 | 82 | 69 | 186 |
| g-112a | 380v 50hz | 60 | 0.24 | 2800 | 1000 | 110 | 71 | 210 |
| g-132a | 380v 50hz | 60 | 0.24 | 2800 | 1000 | 70 | 74 | 250 |
| g-160a | 380v 50hz | 60 | 0.24 | 2800 | 1000 | 40 | 65 | 300 |
| g-180a | 380v 50hz | 180 | 0.71 | 1400 | 1200 | 55 | 69 | 340 |
| g-200a | 380v 50hz | 180 | 0.71 | 1400 | 1800 | 65 | 70 | 380 |
| g-225a | 380v 50hz | 230 | 0.71 | 1400 | 2750 | 82 | 76 | 430 |
| g-250a | 380v 50hz | 230 | 0.71 | 1400 | 3300 | 85 | 77 | 470 |
| g-280a | 380v 50hz | 370/280 | 1.1 | 1400 | 4000 | 110 | 79 | 530 |
| g-315a | 380v 50hz | 370/500 | 1.45 | 1400 | 5200 | 150 | 80 | 600 |
| g-355a | 380v 50hz | 500 | 1.8 | 900 | 6200 | 100 | 75 | 680 |
| g-400a | 380v 50hz | 500 | 1.8 | 900 | 6500 | 85 | 78 | 720 |
